Automatic Fueling Nozzle JY2101-11B

This automatic fueling nozzle is designed for prepaid self-service and cassette systems to prevent oil spills. When the oil pump system is pressurized to a certain extent, the automatic fueling nozzle can be opened; when there is no pressure, the fuel nozzle will automatically close. Therefore, when the fuel gun is placed in the dispenser storage position, it is closed.

Materials of Fuel nozzles JY2101-11B

Body: Aluminum
Seals: Buna-N, Won
Main stem seals: Viton Cased Oil Seal / Graphite with Teflon
Main stem: Stainless steel

Features of Fueling Nozzles

◈Accurate flow control: Users can fill up the fuel tank according to the exact amount of oil they need, and it is very easy to stop the fuel supply accurately.
◈Easy to replace the oil outlet pipe – only need to remove the screw on the oil outlet pipe and replace the new oil outlet pipe, related accessories can be obtained from JAYO.
◈Small aluminum frame – light weight, easy to operate, unique and novel in appearance.
◈Easy to full-service normally open gear: One-handed control, convenient and quick to set the flow rate for the customer.
◈Unique two-stage control system: It can effectively close the passage to ensure that the oil in the pipeline is not lost. Even if the handle of the oil gun is opened and there is not enough pressure in the pipeline, the main valve of the oil gun will always remain closed.
◈Integral insulated holster – protects the refueling gun and vehicle, and isolates the user’s hands from damage.
◈Color selection – color can be customized.
◈Optional splash guard.
◈Optional oil outlet pipe with attitude lock – when the oil outlet pipe is tilted upwards more than the horizontal position, the oil gun will be automatically closed to prevent leakage and accidents.
◈100% factory inspection.

Warning: Using other objects to keep the automatic fueling nozzles in the normally open state will cause the fuel gun to fail to close and personal injury.

Package info of Fuel Nozzle JY2101-11B

Net Weight: 1.275kg/pc

Gross Weight: 1.5kg/pc

55 x 34 x 42.5cm3/case of 15pc

Technical Parameter of Fueling Nozzle JY2101-11B

Model Inlet Size Outlet Diameter Flow Rate Working Pressure
JY2101-11B BSP3/4’’ / NPT3/4’’ 15/16’’ 0-60L/m 0.18㎫
JY2101-11BP BSP3/4’’ / NPT3/4’’ 13/16’’ 0-45L/m 0.18㎫
